CSF 7227 High-Performance All Aluminum Radiator for PORSCHE Cayenne (955/957)
This item is considered special order and is not available for immediate pickup or dispatch. Price and ETA may vary. Please note that no returns, cancellations, or refunds allowed on special orders.
The CSF radiator features the latest 5mm fin technology. The smaller fin height significantly increases the heat exchange surface area improving overall cooling efficiency and recovery. A larger 2-Row 42mm aluminum core increases the fluid capacity of the radiator, and improves the cores ability to dissipate heat. CSF’s Exclusive B-Tube Technology increases the heat transfer by approximately 15% over regular oval welded tubes. In addition, the ultra-efficient multi-louvered fins maximize airflow through the core for the best possible performance.
The TIG-Welded 100% All Aluminum construction increases the overall strength of the radiator. This improves durability and longevity so you can be confident it will hold up to hard driving conditions. The CSF radiator mounts in the factory location and requires no modifications or cutting to install.
- 2-Row, 42mm Ultra-High-Performance Core
- Cooling Tubes with CSF’s Exclusive B-Tube Technology
- New 5mm Tall Ultra Efficient Fins with a Multi-Louvered Design for Maximum Surface Area Contact
- CNC Machined Mounting Brackets and OEM Style Inlet/Outlet
- 100% All Aluminum TIG-Welded Construction
- Hand Brushed Satin Finish
- True Plug-and-Play “Drop-in Fit” Installation Requires Absolutely No Modifications
- Individually Leak and Pressure Tested
- 2-Year Limited Warranty
Applications:
- 2003-2006 Porsche Cayenne (3.2L V6 & 4.5L V8 – N/A & Turbo) – 955 / 9PA
- 2008-2010 Porsche Cayenne (3.6L V6 & 4.8L V8 – N/A & Turbo) – 957 / 9PA
- 2007-2010 Audi Q7 (3.6L V6 & 4.2L V6)
- 2008-2015 Audi Q7 (3.0L V6 TDI & 4.2L V8 TDI)
- 2011-2015 Audi Q7 (3.0L V6 TFSI)
- 2004-2007 Volkswagen Touareg (3.2L V6)
- 2004-2008 Volkswagen Touareg (5.0L V10 TDI)
- 2004-2009 Volkswagen Touareg (4.2L V8)
- 2007-2010 Volkswagen Touareg (3.6L V6)
- 2009-2010 Volkswagen Touareg (3.0L V6 TDI)
OEM Part Numbers:
- Porsche: 955 106 142 01
- Audi / VW: 7L0 121 253 A
