CSF 7250 High Performance Cooling Radiator for FERRARI FF / GTC4Lusso / F12 / 812 / Monza

Description CSF 7250 High Performance Cooling Radiator for FERRARI FF / GTC4Lusso / F12 / 812 / Monza

The CSF radiators feature the latest 5mm multi-louvered fins. These fins significantly increase the heat exchange surface area improving overall cooling efficiency and recovery while still maintaining good airflow. Each core is 28% larger than the original FF/GTC4Lusso Radiator and 14% larger than the F12 / 812 / Monza Radiator. This core volume difference comes from the thicker 2-Row 42mm aluminum core. This both increases the fluid capacity of the radiator, and improves the core’s ability to dissipate heat. The use of CSF’s 5mm fins also allowed for an additional cooling tube and fin row.

CSF’s Exclusive B-Tube Technology increases the heat transfer by approximately 15% over regular oval welded tubes. Combined with the new 5mm fins, heat transfer is increased by up to 25% overall. In addition, the super-efficient multi-louvered fins maximize airflow through the core for the best possible performance.

The combination of TIG-Welded 100% All Aluminum construction increases the overall strength of the radiator. This improves durability and longevity so you can be confident it will hold up to hard driving conditions. Additionally, the satin black finish gives the radiator a clean OEM look and both radiators are a true Plug-and-Play “Drop-in Fit” application.

Features:

• 2-Row – 42mm Ultra-High-Performance Core
• Cooling Tubes with CSF’s Exclusive B-Tube Technology
• New 5mm Tall Ultra Efficient Fins with a Multi-Louvered Design for Maximum Surface Area Contact
• CNC Machined Mounting Brackets and OEM Style Double Barbed Inlet/Outlet Connections
• 100% All Aluminum TIG-Welded Construction
• Satin Black Finish
• True Plug-and-Play “Drop-in Fit” Installation Requires Absolutely No Modifications
• Individually Leak and Pressure Tested
• 2-Year Limited Warranty

Applications:

• Ferrari FF 2011-2016
• Ferrari GTC4Lusso (excl. GTC4Lusso T) 2017-2020
• Ferrari F12 Berlinetta 2013-2017
• Ferrari F12TDF 2016-2017
• Ferrari 812 Superfast 2018-2022
• Ferrari 812 GTS 2020-2024
• Ferrari 812 2024-
• Ferrari Monza SP1 2023-
• Ferrari Monza SP2 2023-

OEM Part Numbers:

• Ferrari: 263427 (FF / GTC4Lusso)
• Ferrari: 333926 (F12 / GTC4Lusso)
• Ferrari: 319867 (812 / Monza)
