GARRETT 836026-5005S Turbocharger GT2860R TRIM 62 A/R 0.60 Photo-0

GARRETT 836026-5005S Turbocharger GT2860R TRIM 62 A/R 0.60

€1.040,06

VAT included. Shipping calculated at checkout

GARRETT P/N: 836026-5005S
Available for order at Partners Worldwide Usually ready in 1-2 weeks updated 19.10.2025
Quantity:

This item is considered special order and is not available for immediate pickup or dispatch. Price and ETA may vary. Please note that no returns, cancellations, or refunds allowed on special orders.

Pickup available at Kelberg Warehouse Usually ready in 24 hours

GARRETT 836026-5005S Turbocharger GT2860R TRIM 62 A/R 0.60

Kelberg Warehouse

Pickup available, usually ready in 24 hours

Auf der Struth 4
53539 Kelberg
Germany

+4926916879995

Ball bearing
Oil & Water cooled bearign system
T25 turbine inlet flange with threaded bolt holes instead of traditional through holes.
Turbine housing has a unique "compact" 5-bolt outlet that is not interchangeable with traditional T25 5-bolt outlets.
Turbine housing is cast from high-nickel "Ni-Resist" material for extreme applications.
Turbine wheel is cast from "Inconel" material for extreme applications.
Direct replacement upgrade turbocharger for GT2556R (702987-0007) used on Nissan Skyline R34 GT-R.
Great size for applications w/packing constrains.
Ideal for smaller displacement engines making up to 360 Hp.
Turbine housing option available

Turbo Part Number Model Turbine side Compressor side
New Part Old Part O.D.mm I.D.mm TRIM A/R O.D.mm I.D.mm TRIM A/R
836026-5005S 707160-5005S GT2860R 53.8 47.0 76 .64 60.0 47.0 62 .60


HORSEPOWER 350HP - 360HP
DISPLACEMENT 1.8L - 3.0L

C.H.R.A. Part Number
New Part CHRA Old Part CHRA
835998-5006S 446179-5051S

Applicable Garrett P/N's:
707160-0005
GT2860R
446179-0051
707160-5
707160-05
707160-5005S

836026-5
836026-5005
836026-05
836026-5005S
