HKS 13001-AH007 Intercooler Kit for HONDA Civic Type-R (FL5) 2022-

Intercooler Core

A huge 22.4% increase in core’s area leads to immense improvement in cooling. The OEM core does not provide sufficient cooling capacity when boosting up, with increased core capacity it will be compatible with everything from boosting up to turbo upgrade. The core is designed to be also installed with OEM piping.

Piping Kit

Upon enlarging the pipe diameter and smoothing out the inner design in comparison to OEM we are able to increase power output. The OEM hose is prone to expand under high boost, but aluminum pipe has completely solved the issue of pressure loss due to hose expansion. The aluminum pipe is given a mirror buff finish, and the cast pipe and core feature the HKS logo, which gives a fantastic dress-up look.

• Core size: 695×178×100
• Core specs: 10 Fins, 9 Tubes
• Tank: Aluminum cast

Performance Data

• Power: 245kW(333 PS) / 6500 rpm
• Temp: I/C outlet 30.3℃ (7000 rpm)
• Cooling Efficiency: 88% (7000 rpm)
• Pressure loss reduction: 12.4kPa (7000rpm)

Piping Kit

• Aluminum bent pipe (IN/OUT)
• Cast pipe (IN/OUT)
• Silicone hose
• Hose band
• Bracket (IN/OUT)
• Special bolts and nuts

Notes

• To install the intercooler ASSY, it is necessary to modify the air guide inside the bumper and relocate the outside air temperature sensor. No modification of the reinforcement is required.
• To install the piping, it is necessary to shave the bracket on the vehicle body
