Description HKS 42018-AT024 Boost Controller Power Editor R for TOYOTA GR Yaris Gen2 (GXPA16) 2024-
The HKS Power Editor R is a model-specific boost-up controller developed for the Toyota GR Yaris Gen 2. By connecting inline with the vehicle’s sensor harness, the system allows an easy and reliable increase in boost pressure. The included harness is designed specifically for the GR Yaris Gen 2, enabling a true plug-and-play installation without wiring modifications.
Unlike many conventional boost-up products that rely only on engine RPM signals, the Power Editor R also utilizes vehicle speed and throttle position signals. This enables optimal boost correction for each gear and throttle opening, delivering smooth and consistent power across the entire RPM range.
The Power Editor R included in this kit comes preloaded with boost-up data, allowing immediate performance enhancement after installation. In addition, users can create custom control data using the free Easy Writer for Power Editor R software to fine-tune settings according to individual vehicle characteristics.
- Inline plug-and-play installation with vehicle-specific GR Yaris Gen 2 harness
- Uses multiple signals including RPM, vehicle speed, and throttle position
- Preloaded boost-up data included
- Custom tuning supported via free Easy Writer software
- Return connector allows easy restoration to stock condition
The Power Editor R connects to the vehicle’s sensors as follows, assigning each signal to the corresponding control channel:
- CH1: Boost Pressure Sensor
- CH2: Intake Manifold Pressure Sensor
- CH3: Fuel Pressure Sensor
- CH4: Throttle Position Sensor
- CH5: Mass Air Flow Meter
- Cam Angle Sensor (RPM signal)
- Vehicle Speed Signal (optional)
By using data from multiple sensors for precise control, the system significantly enhances low- to mid-range torque while maintaining strong high-RPM power. This results in a driving experience that is both manageable and impressively powerful.
