MANLEY 14162-1 ROD-BBC 6.385 I BEAM

MANLEY 14162-1 ROD-BBC 6.385 I BEAM

€313,24

VAT included. Shipping calculated at checkout

MANLEY P/N: 14162-1 GTIN: 807298004181
Quantity:

This item is considered special order and is not available for immediate pickup or dispatch. Price and ETA may vary. Please note that no returns, cancellations, or refunds allowed on special orders.

Pickup available at Kelberg Warehouse Usually ready in 24 hours

MANLEY 14162-1 ROD-BBC 6.385 I BEAM

Kelberg Warehouse

Pickup available, usually ready in 24 hours

Auf der Struth 4
53539 Kelberg
Germany

+491732982897

Description MANLEY 14162-1 Pro Series I-Beam Connecting Rod – Chevrolet Big Block

Manley’s Turbo Tuff I-Beam Connecting Rods represent precision, performance, and quality. Engineered with meticulous attention to detail and a finely tuned manufacturing process, these rods are a testament to Manley’s commitment to excellence.

Pro Series rods are designed for ultimate performance.

  • Available in forged 4340 or 300M vacuum-degassed steel alloys.
  • Certain Pro Series I-Beam SKUs have earned “NHRA Legal” certification for Stock and Super Stock racing categories.
  • Available in Tour Lite, Lightweight, Standard Weight, and Heavy Weight options for specific markets.

Specifications:

  • Average Gram Weight: 565 GR
  • Big End Bore: 2.008 IN
  • Center To Center Length: 4.783 IN
  • Journal Size: Stock
  • Length: Stock
  • Pin End Bore: 0.8671 IN
  • Wrist Pin Diameter: 0.866 IN
  • Connecting Rod Series: Pro Series I-Beam
  • Connecting Rod Sub-Series: Turbo Tuff
  • Rod Quantity: 1
  • Rod Bolt Material: ARP 2000
  • Connecting Rod Type: I-Beam
  • Connecting Rod Material: 4340
