TECHART 000.200.380.009-02 Air Suspension Module Sport for PORSCHE Macan (95B.1/95B.2/95B.3)

Description TECHART 000.200.380.009-02 Air Suspension Module Sport for PORSCHE Macan (95B.1/95B.2/95B.3)

The TECHART 000.200.380.009-02 Air Suspension Module Sport is designed for PORSCHE Macan 95B.1, 95B.2, and 95B.3 models equipped with Porsche air suspension.

The TECHART Air Suspension Module Sport adjusts the ride height levels for a more direct and agile suspension setup. At Normal Level, the chassis is lowered by 10 mm compared to the standard air suspension. In Sport Plus mode and Low Level, the vehicle is lowered by an additional 20 mm. Terrain Level remains unchanged compared to the standard setting.

The module also provides a lowered Loading Level for easier luggage compartment access and an Automatic Parking Level feature, which lowers the body by another 30 mm after locking the vehicle if Low Level was selected before.

• TECHART Air Suspension Module Sport for PORSCHE Macan models with Porsche air suspension
• Normal Level lowered by 10 mm compared to standard air suspension
• Sport Plus mode and Low Level lowered by an additional 20 mm
• Terrain Level remains unchanged
• Lowered Loading Level for easier luggage compartment loading
• Automatic Parking Level lowers the body by another 30 mm after locking the vehicle when Low Level was selected before
• Not suitable for 95B.3 GTS and T models

Specifications:

• Suspension Compatibility: Vehicles with Porsche air suspension
• Compatibility Restriction: Not for 95B.3 GTS and T
• Terrain Level TECHART: +40 mm (Standard: +40 mm)
• Normal Level TECHART: -10 mm (Standard: +/-0 mm)
• Low Level TECHART: -30 mm (Standard: -10 mm)
• Loading Level TECHART: -50 mm (Standard: -40 mm)
• Automatic Parking Level Standard: Not available
• Automatic Parking Level TECHART: -60 mm
