TIAL 001608 Q SPRING 10 SPRING: Silver (Plain), -22in/hg
This item is considered special order and is not available for immediate pickup or dispatch. Price and ETA may vary. Please note that no returns, cancellations, or refunds allowed on special orders.
TIAL 001608 Q SPRING 10 SPRING: Silver (Plain), -22in/hg
Kelberg Warehouse
Auf der Struth 4
53539 Kelberg
Germany
Nürburgring Showroom
Nürburgring Boulevard 2
53520 Nürburg
Germany
TiAL Sport Blow-Off Valve Spring Fits Q/QR BOVs
Atmospheric Blow-Off Valve, Supports up to 1,800 HP!
The first revision of TiAL's original blow-off valve, the Q Series flows 60% more than its predecessor and bolts to any standard TiAL flange without welding. An aluminum weld base mounting flange cut for 2-1/2'' pipe and aluminum V-band mounting clamp with stainless steel hardware create a durable corrosion-free appearance. A banjo-type aluminum air fitting and bolt with oversized 10mm hose barb allow quick actuator response. Springs available to accommodate various vacuum levels and supercharged applications.
Features:
- For use on turbo-charged and super-charged applications (Paxton, Vortec, etc.) The body and all internal components are CNC-machined from 6061 aluminum alloy. It features a large 1.98'' (50.5mm) valve.
- The V-Band design aluminum mounting clamp gives a very clean and unique appearance. The clamp uses Stainless Steel hardware for a long lasting, corrosion-free appearance.
- The valve seal utilizes a Viton O-ring that is clamped in place to prevent the possibility of sticking to the seat and pulling out. The valve stem and guide are PTFE-lubricated, hard anodize-coated for wear resistance.
- The Blow Off Valve also comes with a machined aluminum banjo-type air fitting and bolt, with over sized 10mm hose barb for quick actuator response. The actuator has a high temp silicone Nomex-reinforced diaphragm for long life.
- An aluminum weld base mounting flange is furnished with each unit
- Through countless hours of R&D Tial was able to make the same size valve flow a staggering 60% more than the original design - that means 60% more air is blown off per cycle! This is the highest flowing BOV on the market
- A single Q BOV can support up to 1,800hp
- -2 psi spring for supercharged applications
Color anodized aluminum options (Silver, Red, Blue, Purple, Black)
Included with Every Tial Q Series Blow-Off Valve:
- Q Series BOV Assembly
- TiAL V-band Clamp
- V-band Weld Flange
- TiAL Air Fitting
- High Pressure O-ring
