WILWOOD 120-8727 Caliper Powerlite 2-Piston (7912), Anodized

Description WILWOOD 120-8727 Caliper Powerlite 2-Piston (7912), Anodized

The WILWOOD 120-8727 Powerlite caliper is a lightweight 2-piston braking solution designed for motorsport, rally, and high-performance applications. Featuring a radial mount configuration, it provides improved stiffness, precise alignment, and simplified installation with compatible bracket kits.

The caliper body is manufactured from forged aluminum using a stress-flow forging process, enhancing structural integrity and resistance to deformation under load. A compact profile and optimized internal design ensure efficient heat management and consistent braking performance in high-temperature conditions.

• 2-piston radial mount caliper for performance and motorsport use
• Forged aluminum construction with stress-flow technology
• FEA-optimized structure for increased rigidity and reduced deflection
• Compatible with 7912 brake pads with Quick-clip retention system
• SRS stainless steel bridge plates reduce wear and vibration
• Internal fluid passages eliminate external crossover tubes
• Four bleed screws for efficient air evacuation
• Compact design suitable for small wheel and rotor applications
• Radial mounting system for precise caliper alignment

Specifications:

• Piston Count: 2
• Piston Diameter: 1.00 in
• Total Piston Area: 1.58 in²
• Material: Forged aluminum
• Weight: 2.8 lbs
• Mount Type: Radial
• Mount Center: 5.08 in
• Rotor Diameter Range: 9.45 – 11.00 in (240 – 298.5 mm)
• Rotor Width: 0.79 – 0.86 in
• Brake Pad Type: 7912
• Pad Area: 5 in²
• Inlet Thread: 1/8-27 NPT
• Finish: Type III anodized
